Y32-400T TF AnHui 4-column Hydraulic Press
Computer Numerical Control (CNC): Omron NB7W-TW00B
PLC Mitsubishi
Automation and electrical equipment SIEMENS
Hydraulic pump 25YCY14-1B
Valves: TAIFENG
Seals: PARKER
Compression: 4000 kN
Ejection: 630 kN
Return Strength: 500 kN
Stroke: 800 mm
Dispensing Stroke: 300 mm
Maximum light aperture: 1250 mm
Speed in progress:
-Free lift: 100 mm
-Under pressure: 4-10 mm
-Return: 70 mm
Speed of dispensing:
-Dispensing: 55 mm
-Return: 145
Table/Ram 1250x1250 mm
Dimensions: 3500x1600x4850 mm
Power (main motor): 22 kW
