P6736 Hydraulic Press for Railway Wheelsets
Manufactured by Pressmash plant (Ukraine)
Еffort 4000 kN
Main cylinder plunger stroke, mm/sec:
- approach speed 40...50
- pressing speed 1...3,5
- retract speed 35...70
Nominal liquid pressure MPa 20
Max. distance between plunger and supporting traverse 2930 mm
Adjustable distance between plunger and supporting traverse 2500 mm
Min. distance between wheels during unpressing 800 mm
Distance between plunger axis and floor 1050 mm
Supporting traverse movement speed 50 mm/s
Max workpiece diameter 1500 mm,
Distance b/n press axis and floor 1090 mm
Total power requirement 19,25 kW,
Overall dimensions LxWxH 6600x2330x2275 mm
Weight approx. 19 t
