Knuckle Joint Forging Press PINSK KB 8336 400T
YOM 1991, Mach No. 1001
Maximum force 400 to
Table dimensions 500x500 mm
Ram stroke 130 mm
Number of strokes per minute : 50
Distance between Plate Stamp & Slider: 475 mm
Adjustment Bolster & Slider: 12 mm
Stroke down ejector 80 mm
Force down ejector 12 to
Stroke upper ejector 16 mm
Force upper ejector 4 to
Air per one switch 2,8 L
Dimensions :
Weight 8425 Kg
Length 1,940 m
Width 1,240 m
Height 2,800 m
Power Required : 380V/ 50Hz / Motor Cap. 12Kw
