Cylindrical grinding machine STANKO 3A164A
Semi-automatic machine
Fully reconditioned machine in 2020

Max. workpiece diameter- 400 mm
Max. workpiece length- 2800 mm
Spindle rotation frequency: 16-1460 rpm
Workpiece spindle speed 3-180 rpm
Max. diameter of grinding:
-In steady rest- 120 mm
-Without steady rest- 360 mm
Max. grinding length- 2500 mm
Height of centers above the table- 210 mm
Max. work-piece weight- 1000 kg
Spindle taper- Morze б
Nominal diameter- 100 mm
Max. length of table travel- 2500 mm
Cutting speed- 35 m/sec
Max. travel of grinding headstock- 235 mm
Grinding wheel dia min/max 500-750 mm
Grinding wheel width 75 mm
Motor power: 13 kW
Periodical feed of grinding headstock:
-Max.: 0,030±0,0025 mm
-Min.: 0,0025±0,0006 mm
Max. axial travel of grinding headstock spindle: ±2,5 mm

Rests- 3 pcs
Sharpening device
Stand and mandrel for balancing of the grinding wheel
Variable speed control for spindle rotation
