ELB Super Rubin 024 NC-K Surface Grinder
ELB Super Rubin 024 NC-K Surface Grinding machine
Equipped with SIEMENS SIMATIC TD 400C Operator Interface Panel
Machine no. 182570982
grinding length 600 mm
grinding width 300 mm
workpiece height 375 mm
Magnetic table 550 x 250 mm
Table bed 900x250 mm
Distance table- spindle 525 mm
Grinding wheel 300x76,2x50 mm
Table stroke 10 - 620 mm
Auto cross feed. Reverse: 3 mm - 2/3 wheel width
Auto cross feed. Transverse stroke: 310 mm
speed: 1.2 - 1200 mm / min
Wheel speed: 1000-3500 rpm
Table load: 300 kg
Weight of the machine ca. 3300 kg
Equipped with SIEMENS SIMATIC TD 400C Operator Interface Panel
Machine no. 182570982
grinding length 600 mm
grinding width 300 mm
workpiece height 375 mm
Magnetic table 550 x 250 mm
Table bed 900x250 mm
Distance table- spindle 525 mm
Grinding wheel 300x76,2x50 mm
Table stroke 10 - 620 mm
Auto cross feed. Reverse: 3 mm - 2/3 wheel width
Auto cross feed. Transverse stroke: 310 mm
speed: 1.2 - 1200 mm / min
Wheel speed: 1000-3500 rpm
Table load: 300 kg
Weight of the machine ca. 3300 kg
Rating
5000reviews
0 vote
Favoured:
0
Listing Details
Type
Grinding machines
Producer
ELB SCHLIFF
Model
Super Rubin 024 NC-K
